HANDLE AND TOWEL BAR INSTALLATION

18

7a.

7b.

Using an hex key to install the towel barr as shown.

Install the handle as shown.

INTERIOR

SHOWER SIDE

INTERIOR

SHOWER SIDE

7B-2

7A-1

7A-2

7B-1

INTERIOR

SHOWER SIDE

INTERIOR

SHOWER SIDE

INSTALLATION MANUAL
