Connectors Location


KTA70M/mITX Users Guide

KTA70M/mITX Users Guide


mPCIe J38

4.2

KTA70m/mITX Bottomview










mSATA J39

HDT+ J32

(not mounted)

Bp J33

(not mounted)
