LOCATION OF CONTROLS AND INDICATORS
20
1.) Speakers.
2.) PROGRAM Button.
3.) REPEAT Button.
4.) STOP Button.
5.) FUNCTION Selector Switch.
(CD/POWER OFF/RADIO)
6.) VOLUME Control.
7.) CD Door.
8.) FM Telescopic Antenna.
9.) Carrying Handle.
10.) CD Door OPEN/CLOSE Position.
11.) Dial Scale.
12.) TUNING Control.
13.) BAND Selector Switch.
(FM STEREO/FM/AM)
14.) PLAY/PAUSE Button.
15.) FWD. Skip Button.
16.) REV. Skip Button.
17.) CD Display.
18.) STEREO FM Indicator.
19.) AC Cord Socket.
20.) PHONES Jack.
21.) Battery Compartment.
(Bottom Cabinet)
19
21
Front Panel
Back Panel
1
2
3
5
6
7
8
9
10
11
12
13
14
15
16
4
1
17
18
