J [ Timer Function S pecifications
This feature allows you to rearrange channels
according to your preference.
O Press the Q key.The Main menu is
displayed on the screen.
Q With the cursor, select the Install menu
followed by the Sort menu,
e Use the or key to select the
channel number you want to change
• Picture
• Sound
from (e.g. 001) and confirm selection with
the ^B key.
Q Use the ^B or ^B key to select the
channel number you want to change to
(e.g. 004) and confirm selection with the
^B key.
The change is done. Channel 4 will move up to
channel 3 and channel 3 will move up to channel
Z
Q Repeat steps Q and Q for each
channel you wish to change.
O To quit the menus, press @ .
Channel edit
This feature allows you to skip or edit
channels which have bad or weak TV signal or
channels you do not watch often.
Once a channel is skipped, you cannot have
access to it by the Channel + or- key.You can
only access the channels by the digit (0-9) keys.
O Press the jp key.The Main menu is
displayed on the screen.
0 With the cursor, select the Install menu
followed by the Edit menu.
0 Enter into the menu and select the
channel number you wish to skip by the
digit keys.
0 Then use the ^B key to select Skipped.
Use the ^B key to select On.
0 Repeat steps e and 0 for each
channel you wish to skip.
0 To quit the menus, press 0.
To restore skipped channels
0 Repeat steps 0 to 0 above.
0 Use the ^B key to select Skipped and
the CB key to select Off.
0 Repeat steps 0 and 0 for each
channel you wish to skip.
0 To quit the menus, press 0.
This feature allows you to set the timer to
switch to a channel at a specified time while
you are watching another channel or when the
TV is on standby mode.
Note; Timer will be disabled once the set is
switched off.
0 Press 0, use the key to select
Features and press the ^B key.
The Features menu is displayed.
. Pleure
' initall 1
1 MB
■ Format Start Time
* DigiSignalMeter Stop time
* Eye-Fi Channel
* Games Activate
Display u
0 Use the ^B key to select Timer.
GSEIS9
You can block certain channels or inhibit use
of the TV set completely.
Note:You can only access the locked channels via
the remote control. Keep the remote control in a
safe place.
0 Press 0, use the key to select
Features and press the ^B key.
The Features menu is displayed.
Description of function:
Time; enter the current time.
Start Time: enter the time for the TV to
switch on or to switch channel.
Stop Time: enter the time to switch to
standby.
Note: If Stop Time is not keyed in. Tv will go to
standby mode after 4 hours.To switch on the TV
from standby, press Channel + or - digit or
Power key.
Channel: enter the channel to switch to.
Activate: enter mode of activating timer;
Once, Daily or Off.
Display: select On to display the time on the
TV screen.
0 Press the 0 key to exit.
0 Use the ^B key to select Child Lock
and press the ^B key to enter,
e Key in the 4-digit access code, for the
first time or if you have forgotten the
code, enter 0711 twice.
There will be a prompt to key in the
New Code.
0 Key in your preferred code once and
again to confirm.
The Child Lock menu is displayed.
0 Use the ^B or ^9 key to select a function
and the ^B key to enter or confirm
selection.
002 * Change Code 003 • Clear All 004 • Lock All oos 006
007
Description of function:
Lock Channel: use the ^B or ^B key
to select a channel number to lock and
press the ^B key to confirm. The S
symbol will display next to the channel
that was locked.
Change Code: enter a new code and
again to confiorm.
Clear All: use to unlock all locked
channels. Select On to activate.
L ock A ll : use to lock all TV and external
channels. Select On to activate.
0 Press 0 to exit.
The DCV monitors and adjusts incoming
video signals to help provide the best picture
quality.When you choose to turn the
DCV to On or Display On, the Brightness,
Colour, Contrast, Sharpness, Dig! Contrast
and Digi Picture++ features are controlled
automatically. DCV adjusts these picture
settings continuously and automatically.
0 Enter Features menu as described in
“Features settings” on the previous page.
o Use the ^B key to select DCV and
press the ^B key to select Off, On
or Display On.
0 Press the 0 key to exit.
Description of option:
Offi the DCV will not be activated.
On: the DCV will work to give the viewer
the best possible picture, but will not
display the monitoring screen when
channels are changed.
Display On: an DCV monitoring screen will
be shown for a few seconds whenever
a channel is changed.
Light Sensor On: The picture get's adjusted
to ambient room light.
Note : Intelligent TV On-Off allows for further improvement in picture quality
(switch off Intelligent TV if it interferes with the picture).
The split screen display shows the image
performance before and after enhancements
to present clearly the effects of the picture
enhancement features.
The screen is split to dramatically show the
comparative images side by side.
0 Enter Features menu as described in
“Features settings” on the previous page.
0 Use the ^B key to select Demo and
press the ^B key to select On or Off.
without picture
enhancements with picture
enhancements
1 Specifications 1
Model Tvoe 14Vardaan &14PT1415 20 Vardaan & 20PT2015 21 Vardaan & 21PT2104
Picture tube screen size (Diagonal) 36 cm 51 cm 53 cm
Picture tube visible size (Diagonal) 35.7 cm 50.3 cm 52.7 cm
Audio Output (PMPO) SOW SOW 200 W
TV System PALB/G PALB/G PAL B/G, ECO AV Stereo
Colour System NTSC 4.43,3.58 Piayback NTSC 4.43, 3.58 Playback NTSC 4.43, 3.58 Playback
Sound System B/G 5.5 B/G 5.5 B/G 5.5
Antenna Input 75 Ohms coaxial 75 Ohms coaxial 75 Ohms coaxial
Externai connections Rear AV IN & OUT Rear AV IN & OUT Rear AV IN & OUT
Operating Voitage / Freguenev 150-276 Volts/50Hz 150-276 Volts/50Hz 150-276 Volts/50Hz
Power consumption (normal) 38W+/-10% 50W+/-10% 60W+/-10%
standby Power <3W <3W <3W
Set Dimensions: Width 36 cm 49.5 cm 60 cm
Depth 38 cm 48.5 cm 49 cm
Height 35 cm 45.5 cm 47 cm
Net Weight (apgx.only) 9.5 Kg 18 Kg 22 Kg
Specifications
Model Type 14 Vardaan DS & 14PT2204 20 Vardaan DS & 20PT2204 21RF Vardaan
Picture tube screen size (Diagonal) 36 cm 51 cm 53 cm
Picture tube visible size (Diagonal) 35.7 cm 50.6 cm 51.6cm
Audio Output (PMPO) 100 W 200 W 200 W
TV System PALB/G PALB/G, ECO AV Stereo PAL B/G, ECO AV Stereo
Colour System NTSC 4.43, 3.58 Playback NTSC 4.43,3.58 Playback NTSC 4.43, 3.58 Playback
Sound System B/G 5.5 B/G 5.5 B/G 5.5
Antenna Input 75 Ohms coaxial 75 Ohms coaxial 75 Ohms coaxial
External connections Rear AV IN & our & Front AV IN Rear AV IN & OUT Rear AV IN & OUT
Operating Voltage / Freguenev 150-276 Volts/50Hz 150 - 276 Volta/50Hz 150-276 Volta/50Hz
Power consumption (normal) 38W+/-10% 60W+/-10% 55W+/-10%
Standby Power <3W <3W <3W
Set Dimensions: Width 45.5 cm 59 cm 60 cm
Depth 38.5 cm 45 cm 52 cm
Height 35.5 cm 47 cm 46 cm
Net Weight (appx.only) 10 Kg 19 Kg 25 Kg
Specifications
Model Type 21PT2216 21PT2443 21PT3442
Picture tube screen size (Diagonal) 53 cm 53 cm 53 cm
Picture tube visible size (Diagonal) 52.7 cm 51.6 cm 52.3 cm
Audio Output (PMPO) 200 W 200 W 400 W
TV System PAL B/G, ECO AV Stereo PAL B/G, AV Stereo PAL B/G, AV Stereo
Colour System NTSC 4.43, 3.58 Playback NTSC 4.43, 3.58 Playback NTSC 4.43,3.58 Playback
Sound System B/G 5.5 B/G 5.5 B/G 5.5
Antenna Input 75 Ohms coaxial 75 Ohms coaxial 75 Ohms coaxial
External connections RearAV IN & OUT RearAV IN & OUT RearAV IN & OUT
Operating Voltage / Freguenev 150-276 Volts/50Hz 150-276 Volts/50Hz 150-276 Volts/50Hz
Power consumption (normal) 55W+/-10% 55W+/-10% 60W+/-10%
standby Power <1W < 1W <1W
Set Dimensions: Width 52.2 cm 60 cm 62.7 cm
Depth 47.9 cm 52 cm 50.5 cm
Height 46.1 cm 46 cm 46.5 cm
Net Weight (appx.only) 23.5 Kg 25 Kg 25 Kg
Picture settings
0 Press 0 then ^B. The Picture menu
will be called up.
0 Use the ^B or ^B keys to select a
setting and the ^9 or ^B ke
Note: during the picture adjustment, only
the selected line remains displayed. Press
^B or ^B to display the menu again.
0 Press 0 to exit.
Sound settings
0 Press 0 , select Sound (^B) and press
^B. The Sound menu will be called up.
______
• PIctur« • rtrejat • Baee j
• AVL
* Digi Bass
I key to select a setting
I key to adjust
0 Use the ^B or C
and the ^B or C
0 Press 0 to exit
Features settings
0 Press 0 , select Features (^B) and press
^B. The Features menu will be called up.
. Picture Timer • Sound Power Saver 13 Format * Install DigiSignalMeter
Eye-Fi
Games
Description of the adjustments:
* Brightness: this changes picture brillance.
* Colour this changes the intensity of the
colour.
■ Contrast: this changes the difference
between the light and dark tones.
* Sharpness: this changes the picture
definition.
* Hue: this adjusts the skin colour tone in
NTSC channel.
■ Digi Color +: this changes the colour
rendering: Cold(bluer), Normal(balanced) or
Warm (redder).
■ Digi Picture++: attenuates picture noise
(snow) in difficult reception conditions.
« Digi Contrast: automatic adjustment of the
picture contrast which permanently sets the
darkest part of the picture black.
Description of the adjustments:
• Treble: this alters the high frequency sounds.
■ Bass: this alters the low frequency sounds.
’ Balance: this balances the sound on the left
and right speakers.
■ AVL (Automatic Volume Leveller): this Is used
to limit increases in sound, especially on
channel change or advertising slots.
■ Digi Real Audio (Incredible Surround):
this boost the effect of stereo sound.
* Digi Bass: this is used to enhance bass
output.
Description of the features:
• Timer, Child Lock, Format, Eye-Fi, Dev,
Dev demo. Power Saver, DigiSignalMeter,
Game: see explanation on the next few pages.
This feature enhances your viewing pleasure
by providing you with a choice of two picture
formats:- 4:3 and Expand 4:3.
0 Press 0 , use the ^B or ^B key to select
Features and press the ^B key.
The Features menu is displayed.
0 Use the ^B key to select Format and
press the ^B key to select 4:3 or
Expand 4:3.
0 Press the 0 key to exit.
Description of function:
4:3 - select this format if you want to display
a conventional picture using the full surface of
the screen.
Expand 4:3 - select this format if you want
to expand pictures transmitted in a
‘letterbox’ format (black horizontal bars at
the top and bottom of the screen) to fill up
the entire screen.
°r Y
Letterbox
The Eye-Fi monitors and adjusts incoming
video signals to help provide the best picture
quality.When you choose to turn the
Eye-Fi to On or Display On, the Brightness,
Colour, Contrast, Sharpness, Digi Contrast
and Digi Picture++ features are controlled
automatically. Eye-Fi adjusts these picture
settings continuously and automatically.
. PIcturs
• Sound
■ UJ 111,1
* Install
1
• Timer
• Format
• DigiSignalMeter
■ Games L
0 Enter Features menu as described in
“Features settings” on the previous page.
0 Use the ^9 key to select Eye-Fi and
press the ^B key to select Off, On
or Display On.
0 Press the 0 key to exit.
Description of option:
Offi the Eye-Fi will not be activated.
On: the Eye-Fi will work to give the viewer
the best possible picture, but will not
display the monitoring screen when
channels are changed.
Display On: an Eye-Fi monitoring screen
will be shown for a few seconds
whenever a channel is changed.
DigiSignalMeter is an intelligent feature which measures the incoming signai and
graphically represents the signal strength on your TV screen.
Note : Default mode for Intelligent TV(visible under Picture sub-menu only when
Eye-Fi isswitched On) is either Auto/OfF depending upon the signal condition. It can
be switched On (if defeult Off) for further improvement in picture quality (switch off
Intelligent TV if it interferes with the picture, status is stored per channel).
M K Personal Zapping
A list or series of favourite TV programs can
be selected and stored in the 4 coloured keys
with the Personal Zapping feature.With this
feature you can easily viewed up to a total of
10 preferred channels for each coloured key.
To add channels:
0 Select a channel with the digit keys.
0 Press ® to display list.
0 Press your favourite colour key to store
the channel in step 0.
0 Repeat steps 0to 0 to store more
channels.
0 Press 0 to exit.
To delete channels:
0 Select and press a colour key that has
stored channels repeatedly to select the
channel you want to delete.
0 Press 0 to display list.
0 Press 0 to remove channel.
0 Repeat steps0to0delete more channels.
0 Press 0 to exit.
Power Saver is an environmentally
friendly feature which reduces power
consumption of your TV by switching
to optimal settings for picture and
sound.
Select Power Saver on or
Select steps of 30 minutes
(upto 180 minutes).
Select Game
(Toggle Between Super Race<^
Power Ludo<-> Cricket<->Power Word)
Select Play to start playing
or Help-Line for Rules
To view channels:
Select and press a colour key that has stored
channels repeatedly to select the channel you
want to view.
Picture Tiler ■ Sound Power Saver ✓ Features k Fornat
I Install OigiSignalNeter
Tiler ✓ Power Saver ■ Foriat
Tiler ✓ Power Saver IFornat
■ DigiSignalMeter
■ Eye-Fi
a
Ganes.
Picture Tiner ■ Sound Chi Id Lock ✓ Features ^ Format
■ Install D.C.V
I Timer
i Child Lock
i Fornat
■ D.C.V
■ DigiSignalMeter
✓ Ganes. k Gane
Play
Help-line
✓ Gane
■ Play
■ Help-line
H S pecifications
Specifications
Model Type 21PT2304 21PT2404
Picture tube screen size (Diagonal) 53 cm 53 cm
Picture tube visible size (Diagonal) 52.3 cm 52.3 cm
Audio Output (PMPO) 400 W 1000W
TV System Multi System, AV Stereo Multi System, AV Stereo
Colour System PAL, NTSC 3.58, NTSC 4.43, SECAM PAL, NTSC 3.58, NTSC 4.43, SECAM
Sound System B/G, 1, DK, M B/G, 1, DK, M
Antenna Inout 75 Ohms cpaxial 75 Ohms coaxial
External connections Rear AV IN & OUT & YUV, Side AV IN Rear AV IN & OUT & YUV. Side AV IN
Operating Voltage / Freguenev 150-276 Volts/50Hz 150 - 276 Volts/50Hz
Power consumption (normal) 60W+/-10% 84W4-/-10%
Standby Power <1W < 1W
Set Dimensions: Width 62.7 cm 62.7 cm
Depth 50.5 cm 50.5 cm
Height 46.5 cm 48.7 cm
Net Weight (appx.only) 25 Kg 28 Kg
Specifications
Model Type 29PT2204 29PT2452
Picture tube screen size (Diagonal) 72 cm 72 cm
Picture tube visible size (Diagonal) 69 cm 69 cm
Audio Output (PMPO) 1000W 400 W
TV System Multi System, AV Stereo Multi System, AV Stereo
Colour System PAL, NTSC 3.58, NTSC 4.43. SECAM PAL. NTSC 3.58, NTSC 4.43, SECAM
Sound System B/G, I, DK, M B/G, 1, DK, M
Antenna Input 75 Ohms coaxial 75 Ohms coaxial
External connections Rear AV IN & OUT & YUV, Side AV IN Rear AV IN & OUT & YUV, SVHS IN
Coeratino Voltage / Freguenev 150-276 Volts/50Hz 150 - 276 Volts/50Hz
Power consumption (normal) 114W-F/-10% 85W+/-10%
Standby Power <1W < 1W
Set Dimensions: Width 75.7 cm 78 cm
Depth 49.3 cm 53 cm
Height 58.2 cm 59 cm
Net Weight (appx.only) 45.5 Kg 46 Kg
