16 FORM NO. L-20319-H-1112
INPUT UNIT
ITEM DESCRIPTION QTY
11 Stub Shaft 1
19 Key 2
20 Bearing Flange 1
30 Ball Bearing 2
35 Retaining Ring 2
45 Hex. Head Jam Nut (Not Shown) 4
58 Retaining Ring 2
REPLACEMENT PARTS
The item or balloon number for all Nexen products is used for part
identification on all product parts lists, product price lists, unit
assembly drawings, bills of materials, and instruction manuals. When ordering replacement parts, specify model designation, item
number, part description, and quantity. Purchase replacement
parts through your local Nexen Distributor.
FIGURE 24
19
11
58
30
35
20
30
35
58
