8
2. Installing and Connecting
2.13 Diagram Icons
Analogue signal
IEC mains supply
S/PDIF digital audio signal
USB audio data
Optional DAB radio
Headphones
Optional FM radio
RC5 remote control signal
W-Fi aerial
Bluetooth aerial
Wired network
2.0
1.0
Firmware upgrade socket
Optional XPS power supply
Optional 555PS power supply
Optional XP5 XS power supply
Volume control
Logo touch mute and un-mute
Signal Ground Switch
