Mercedes-Benz 2013 GLS Class - Manual (Page 70)

BAS operates in emergency braking situa-
tions. If you depress the brake pedal quickly,
BAS automatically boosts the braking force,
thus shortening the stopping distance.
The brakes will function as usual once you
release the brake pedal. BAS is deactivated.
BAS PLUS (Brake Assist System Plus)
General notes
i Observe the "Important safety notes" sec-
tion ( Y page 67).
BAS PLUS is only available on vehicles with
DISTRONIC PLUS.
For BAS PLUS to assist you, the radar sensor
system must be:
R
switched on ( Y page 259)
R
operational
With the help of the radar sensor system, BAS
PLUS can detect obstacles that are in the
path of your vehicle for an extended period of
time.
If the radar sensor system is malfunctioning,
BAS PLUS will not be available. The brake
system is still available with complete brake
boosting effect and BAS.
BAS PLUS provides braking assistance in haz-
ardous situations at speeds greater than
7 km/h.
At speeds of up to approximately 70 km/h
BAS PLUS can also detect stationary objects.
Examples of stationary objects are stopped
or parked vehicles.
Important safety notes
G
WARNING
BAS PLUS cannot always clearly identify
objects and complex traffic situations. BAS
PLUS cannot intervene in these cases. There
is a risk of an accident.
Always pay careful attention to the traffic sit-
uation and be ready to brake.
G
WARNING
BAS PLUS does not react:
R to people or animals
R
to oncoming vehicles
R to crossing traffic
R
when cornering
As a result, BAS PLUS may not intervene in all
critical situations. There is a risk of an acci-
dent.
Always pay careful attention to the traffic sit-
uation and be ready to brake.
In particular, the detection of obstacles can
be impaired if there is:
R
dirt on the sensors or anything else cover-
ing the sensors
R
snow or heavy rain
R
interference by other radar sources
R
the possibility of strong radar reflections,
for example, in multi-storey car parks
R
a narrow vehicle travelling in front, e.g. a
motorcycle
R
a vehicle travelling in front on a different
line
Following damage to the front end of the vehi-
cle, have the configuration and operation of
the radar sensors checked at a qualified spe-
cialist workshop. This also applies to colli-
sions at slow speeds where there is no visible
damage to the front of the vehicle.
Braking assistance
To prevent a collision with the vehicle in front,
BAS PLUS calculates the brake force neces-
sary if:
R
you approach an obstacle, and
R
BAS PLUS has detected a risk of collision
When driving at a speed under 30 km/h:
if you depress the brake pedal, BAS PLUS is
activated. Braking assistance from BAS PLUS
is carried out at the last possible moment.
When driving at a speed greater than
30 km/h: if you depress the brake pedal
68
Driving safety systems
Safety
