Connection and installation – Atlona CP 268 User Manual
Page 6
Advertising
6
www.atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
(1) HDMI display
(2) HDMI switcher
CONNECTION AND INSTALLATION
HDMI Plasma,
LCD or DLP TVs
Computer
HDMI cable
DVD
or
DVI cable
SPDIF Cable
HDMI Plasma,
LCD or DLP TVs
Computer
HDMI cable
DVD
or
DVI cable
HDMI Switcher
SPDIF Cable
