Model Name
AT-HDRP
Technical
Role of usage
Repeater
HDMI™ compliance
HDMI™ 1.3a
DVI compliance
DVI 1.1
HDCP compliance
Yes
Video bandwidth
Single-link 340MHz (10.2Gbps)
Video support
480i / 480p / 720p / 1080i / 1080p60 up to 36-bit color
Audio support
Surround sound (up to 7.1ch) or stereo digital audio
Signal equalization
8-level digital control
Input TMDS signal
1.2 Volts (peak-to-peak)
Input DDC signal
5 Volts (peak-to-peak, TTL)
ESD protection
[1] Human body – ±19kV (air-gap discharge) & ±12kV (contact discharge)
[2] Core chipset – ±8kV
PCB stack-up
4-layer board (impedance control – differential 100W; single 50W)
Input
1x RJ45
Output
1x RJ45
RJ45 connector
WE/SS 8P8C with 2 LED indicators
Rotary control switch
Signal level
Mechanical
Housing
Metal enclosure
Dimensions
[L x W x H]
Model
65 x 39 x 26mm (2.6” x 1.5” x 1”)
Package
175 x 270 x 80mm (6.9” x 10.6” x 3.1”)
Weight
Model
100g (3.5 oz)
Package
420g (15 oz)
Fixedness
Wall-mounting housing and lach-locking power jack
Power supply
5V DC
Power consumption
1 Watt (max)
Operation temperature
0~40
0
C (32~104
0
F)
Storage temperature
-20~60
0
C (-4~140
0
F]
Relative humidity
20~90% RH (no condensation)
SPECIFICATIONS
