On Screen Display Menu
Menu Option Sub-Menu Option Adjustment
CONTRAST - Level 0 ~ 100
BRIGHTNESS - Level 0 ~ 100
FINETUNE - HUE Level 0 ~ 100
- SATURATION Level 0 ~ 100
- SHARPNESS Level 0 ~ 100
- EXIT Back to Menu
COLOR - RED Level 0 ~ 100
- GREEN Level 0 ~ 100
- BLUE Level 0 ~ 100
- EXIT Back to Menu
SIZE - FULL / OVERSCAN / UNDERSCAN /
LETTERBOX / PANSCAN / FOLLOW INPUT
OUTPUT - NATIVE
VGA (640x480) / SVGA (800x600)
XGA (1024x768) / SXGA (1280x1024)
UXGA (1600x1200) / 480i / 480p / 720p59 /
1080i59 / 1080p59 / 576i / 576p / 720p50 /
1080i50 / 1080p50 / WXGA (1280x800)
WSXGA (1680x1050) / WUXGA (1920x1200)
1080p30 / WUXGA+ (1400x900) / SXGA+
(1400x1050) / NATIVE
AUDIO - SOURCE HDMI / TOSLINK / L/R
- DELAY 4 / 11 / 15 (seconds)
- SOUND On / Mute
- EXIT Back to Menu
OSD - HPOSITION 0 ~ 100
- VPOSITION 0 ~ 100
- TIMER 0 ~ 100 (sec.)
- BACKGROUND 0 ~ 100 (transparency level)
- COLOR BAR On: Color bar will display when the
source is disconnected
Off: After the source is disconnected, a
black screen will be active for 50 seconds
before the output signal is shut off
Timeon 15min: Once the source is
discontinued, a color bar will be active
for 15 minutes before the output signal is
shut off
- EXIT Back to Menu
FACTORY RESET - YES
NO
INFORMATION - SOURCE (Input Type)
INPUT (Resolution)
OUTPUT (Resolution)
VERSION (Firmware #)
EXIT - Close the OSD Menu
