SPECIFICATIONS
Technical
Role of usage
SDI standards
SD-SDI, HD-SDI, 3G-SDI
Auto 3G/HD/SD detectionY es
Supported protocols SMPTE 259M, SMPTE 292M, SMPTE 424M, SMPTE 425M
Video bandwidth[ 2.97Gpbs & 2.97/1.001Gbps]
Data rates 270 / 1483 / 1485 / 2967/ 2970 Mbps
Output impedance
Reclocking functionY
es
Cable equalization[ 3G] up to 90m (300ft) [HD] up to 150m (500ft) [SD] up to 300m (1000ft)
Audio supportY es
RP-198 pathological patternsI mmune
PCB stack-up
Input
1x BNC [SDI]
Output 6x BNC [SDI]
BNC connector
Eye pattern characteristics
Amplitude: Within 800mV 3% (<10%) Long time jitter: 0.195g (<1.0g)
Rise overshoot: Less than 2% (<10%) T iming jitter: 0.195g (<1.0g)
Fall overshoot: Less than 2% (<10%) A lignment jitter: 0.127g (<0.2g)
Mechanical
Housing Metal enclosure
Dimensions
[L x W x H]
Model 5.7” x 3.2” x 1” (145 x 80 x 25mm)
Package 10.6” x 6.9” x 3.2” (270 x 175 x 80mm)
Carton 15.7” x 12.6” x 11.8” (450 x 370 x 300mm)
Weight
Model 10.9oz (310g)
Package 1.7lbs (785g)
Fixedness Inter-locked power supply
Power supply 5V 4A DC
Power consumption 10 Watt (max)
Operation temperature 32~104°F (0~40°C)
Storage temperature -4~140°F (-20~60°C)
Relative humidity 20~90% RH (no condensation)
