LE-37C User’s Manual

-25-

Connector: SIMM

Type: 6-pin SIM slot

Pin

Description

Pin

Description

1 SIMVCC

2 SIMRST

3 SIMCLK

4 NC

5 GND

6 SIMVPP

7 SIMDATA

Connector: JMSATA
Type: onboard 3-pin header

JMSATA

Mode

1-2

Support mSATA for MINI_CARD1

2-3

Support PCIe and USB

Default setting: 2-3
