2.9 Audio Interface
The LV-670 series offers the AC97 3D audio with 5.1-channel and S/P DIF
interface based on Intel ICH4 and Realtek ALC650 codec.
JAUDIO
1
5
6
10
CDIN
1 2 3 4
Red: Center / Mic-in
Blue: Rear / Line-in
Green: Front / Line-out
J2
