LP-180 User’s Manual
-
20
-
2.9.2 <Digital Display>
(LP-180X only)
The board provides one 20-pin LVDS connector for 18 bit single channel panel, supports
up to 1400 x 1050 of resolution, with one LCD backlight inverter connector and one
jumper for panel voltage setting.
1
5
CN_INV
1
19
2
20
CN_DDP
JVLCD
3
1
