Admin Web
Access Admin Web
Run the Internet browser on your PC and type in the controller IP address. Factory default IP address is
192.168.1.127. The default password is empty.
Login
This screen isn’t displayed if password is empty (factory
default status).
If password isn’t empty, you have to login at first for
operating with your CUEunit via these web pages.
Enter your password into the Password box and click the
Login button to enter the CUEunit web pages.
Remember that the password is case sensitive. For
changing your password use the Password menu after you
are logged in.
Configuration
Identification
Each CUEunit can be identified by a unique identification
name. Unique names are most useful in applications
requiring more than one CUEunit. This enables
programmers and installers to reference CUEunits with
logical, user friendly names, like “boardroom,” “lobby,”
etc.
To set the CUEunit identity, enter the unique name you
wish to use in the Name box.
Be sure to click the Apply button for any changes to
become effective!
IP Settings
This page is used for setting the communication parameters
for your CUEunit.
The CUEunit uses standard internet protocol (IP)
communication parameters. Certain parameters can be reset
by the user. On start up, this page will display the CUEunit’s
given Physical address (MAC), Current IP address. Carefully
note this addressing information (and any changes you elect
to make to the IP address, subnet mask, or default gateway).
This information must be entered into the Cue Visual
Composer program written for your specific application. For
control systems with more than one CUEunits, a unique IP
address must be given to each CUEunit.
Some control systems are “stand alone” and not part of a
larger network. For such “stand alone” systems, the Host
name is optional. However, for control systems that are
connected to a larger network, please obtain the Host
name from the network administrator, and enter it into the
corresponding box. DHCP is not supported in this release.
Be sure to click the Apply button for any changes to become
effective!
