d&b Bi6-SUB - Manual (Page 8)

2.4. Technical specifications
Bi6-SUB system data
Frequency response (–5 dB standard) 37 Hz - 140 Hz
Frequency response (–5 dB 100 Hz mode) 37 Hz - 110 Hz
Max. sound pressure (1 m, free field)
with D80/D12/D6
134 dB/131 dB/128 dB
(SPLmax peak, pink noise test signal with crest factor of 4)
Bi6-SUB loudspeaker
Nominal impedance 8 ohms
Power handling capacity (RMS/peak 10 ms) 500/2000 W
Components 1 x 18" driver
Connections 2 x NL4 M
1 x screw terminal (ST - up to 4 mm 2 /AWG 11)
Optional fixed cable (PG):
H07-RN-F, 2 x 2.5 mm 2 (AWG 13), 5.5 m (18 ft)
Pin assignment NL4 M: 1+/1–
Fixed cable (PG): Brown: (+) / Blue: (–)
Weight 38 kg (84 lb)
Bi6-SUB cabinet dimensions in mm [inch]
Bi6-SUB frequency response, standard and 100 Hz mode
d&b Bi6-SUB Manual 1.1 en 8
