5. DtEncode Overview
5.1. Launching DtEncode
Start the DtEncode DtEncode DtEncode DtEncode program from the Start Menu: start start start start->All Programs All Programs All Programs All Programs->D D D DekTec ekTec ekTec ekTec->DtEncode DtEncode DtEncode DtEncode, or, if
available from your desktop, click on the DtEncode DtEncode DtEncode DtEncode shortcut.
DtEncode DtEncode DtEncode DtEncode application icon:
DtEncode DtEncode DtEncode DtEncode can be launched from command prompt as well. (See Appendix I for more details)
5.2. DtEncode Application General Layout
Application general view
Item Explanation
1 Menu Bar This area displays Menu controls.
2 TS Tree View This area displays the hierarchical view of the resulting TS.
3 Rate Graph This area displays in real time the TS bitrate (total rate) and the
data bitrate.
4 Source Video Viewer This window provides for visual monitoring of the input.
When performing HD encoding, to reserve the maximum
performance for the encoding process, this video monitor only
refreshes every second.
5 Start Button This button permits to Start/Stop the encoding process.
6 Tab Menu Bar Four Tabs permit the configuration of various settings of
DtEncode
7 Setting per Tab This area provides detailed settings for video, audio, service and
output configuration
2 2 2 2
6 6 6 6
3 3 3 3
5 5 5 5
4 4 4 4
7 7 7 7
1 1 1 1
