FT100 Series Installation & Operation Manual
www.ot-systems.com 7
(4) Cable Connections & Setup Procedures
Signal Type Cable Type Connector
Optical Single-mode or Multi-mode Fibers ST (or FC) Connector
Video Coaxial Video Cable BNC Connector
Typical System Cable Connections Diagram:
Card Module Transmitter Card Module Receiver
Fig 4.1 Card Module to Card Module connection diagram
