FT110DBMicro Series Installation & Operation Manual
www.ot-systems.com 8
(4) Cable Connections & Setup Procedures
4.1 System cable connections
Signal Type Cable Type Connector
Optical Single-mode or Multi-mode fiber ST (or FC) Connector
Data Twisted-pair Cable Screw Terminal Block
Typical System Cable Connections Diagram:
Micro Transmitter Micro Receiver
Fig 4.1 Micro unit to Micro unit connection diagram
