Technical Specifications
Frequency
Range
5 MHz to 1002 MHz
Resolution
50 kHz
Tuning
Frequency or channel
Input
Impedance
75Ω F-type connector
Spectrum Analyzer
Span
2.5, 6.25, 12.5, 25, 62.5, 125, 250,
500 MHz and Full
Scale
5 and 10 dB/div
Automatic and
manual reference
level
Reverse Path Ingress Scan
Range
Selectable 5 to 42MHz, 5 to
68MHz, and 5 to 85MHz
Mode
Peak, Average, Min, and Real-
time
Digital Measurements
Demodulation
ITU-T J.83 Annex A/B/C standard
Support
16, 32, 64, 128 and 256 QAM,
QPSK
Symbol Rate
2 to 6.9 MS/sec
Q.A.L. Technology
(QAM Auto Lock)
Automatic detection of signal
characteristics and modulation
parameters
DFE filter
On / Off
Power
-30 to +60 dBmV
C/N
Up to 45 dB
MER
Up to 40 dB
Accuracy
±2 dB
Resolution
0.1 dB
Pre-BER and Post-
BER (Annex B)
1.0E-3 to 1.0E-8
BER (Annex A/C)
1.0E-3 to 1.0E-8
Constellation
Display
4, 16, 32, 64, 128 and 256 QAM
Zoom Capability
Channel Equalizer
Graphical
representation
Analog Measurements
Level measurement -30 to +60 dBmV
V/A
up to 30 dB
C/N
up to 54 dB
Accuracy
±2 dB
Resolution
0.1 dB
CSO/CTB
Channel Plans
Factory channel
plans
Up to 24 with different world
wide regions
Custom channel
plans (learning
plan)
Up to 16 channel plans
System Scan
Channels
Up to 100 channels (analog and/
or digital)
Measurements
Level bar representation and C/N
BER/MER of the selected channel
Tilt
Channels
Up to 100 channels (analog and/
or digital)
Selectable markers
Pass/Fail Indicators
Factory profiles
Headend, Fiber Nod, Trunk,
Bridge, Line Ext, Tap, End Line,
Ground, Modem/STB, Off Air
Custom profiles
up to 10 profiles
Voltmeter
Range
9V to 150V
Accuracy
±(0.5V +1%)
Hum
Range
2 to 5%
Accuracy
±1%
Speed Test Option 593211
Download and
upload Speed
Up to 20Mbps
Ping times
Service Info Option 593210
Channel
parameters
NIT, PAT, TSID, CBRT
Service parameters SID, VID, AID, bitrate, encode type
Cable Modem (593103)
Modes
Docsis3.0/2.0/1.1/1.0/BPI/BPI+
Dowstream
Up to 8 channels (88-1002MHz)
UpStream
Up to 4 channels (5-42MHz)
Specifications are subject to change without notice.
