APC-3x93P_R (SBC-7106) User Manual 6
Chapter 1 Getting Started
1.1 Features
Fanless and Low Power Consumption Stainless Steel Panel PC

Intel® Atom™ Processor D2550 (1M Cache, 1.8GHz)
 Onboard 2GB DDR3, optional 4G
11~32V DC wide-ranging power input
M12 I/O Connector
Full Flat bezel Design, Total 6 sides IP65/ IP69K
Projective capacitive touch/ Resistive Type
1.2 Specifications
APC-3593P(R)
System
CPU Intel® Atom Processor D2550(1M Cache, 1.8GHz)
Motherboard SBC-7106-D2550
System Chipset Intel NM10 Express
System Memory Onboard DDR3 2GB (Default), optional 4G
IO Port
USB
1 x M12 8 pin for USB 1/2
1 x M12 8 pin for USB 3/4
Serial/Parallel
1 x M12 8pin for COM 1/RS-232/422/485 (Default RS-232)
1 x M12 8pin for COM 2/RS-232
Audio N/A
Membrane control N/A
LAN 1 x M12 8pin for LAN
Power 1 x M12 3 pin DC power connector
Storage Space
HDD 1 x 2.5” SATA HDD or SSD
Movable device 1 x Internal SD Card slot on board
Expansion
On board expansion bus 1 x Mini PCIe half size slot
Display
Display Type
15” TFT-LCD
