6
Chapter 1_____________Getting Started
1.1 Specifications
Model No.
Specs
APC-3519 APC-3719 APC-3919
System
Processor Intel G2 socket, support up to 3
rd
Gen Core i7 3630QM 2.4GHz
Processor
System Chipset Intel HM77
System Memory 2 x 204 Pin DDR3 SO-DIMM, up to 16GB 1066/1333 MHz
Storage 2 x 2.5" SATA HDD space, easily accessible storage design
1 x external CF slot
External I/O
USB 4 x USB 2.0 type A
Serial/Parallel 3 x RS-232 DB9
1 x RS-422/485 selectable default RS-485 DB9
Audio 1 x MIC-in, Line-out phone jack
Graph 1 x DVI-I
LAN 2 x GbE RJ-45
Digital I/O 1 x 8 pin 6 GPIO/VCC/GND terminal block connector for option
KB/MS None
Membrane Control None
Power
1 x 3 pin DC power connector
1 x Rocker switch for power on/off
1 x 2 pin remote power switch
2 x LED light for power and HDD indication
Expansion
On Board Expansion Bus 1 x Mini PCIe full size
Expansion Slot 1 x PCIe x 16 slot default
1 x PCI slot option
OS support Windows XP embedded, Windows embedded standard 7,
Windows 7 Pro for embedded
LCD
Display Type 15” 17” 19”
Max. Resolution 1024X768 1280X1024 1280X1024
Max. Color 262K 16.7M 16.7M
Luminance (cd/m2) 420 350 350
View Angle(H/V) 160:160 170:165 170:165
Backlight Lifetime 50,000 hrs
Touch Screen (option)
Type Resistive Touch
Light Transmission 80%
Power Supply
Power Input DC 9~32V On Board
