ACS-2210A User Manual 23
28. JTAG1:
Reserve.
29. TB-524
(option)
:
ASB-B705 (R1.00/R2.00) expansion card.
(1) Specifications:
Specifications
Board Size 146 mm x 61.5 mm
Power
Managemen
t
DC9V~32V input
1 x 3-pin power input connector （DC_IN）
Display 1 x DB15 (CRT1)
LAN 1 x USB to RJ-45 10/100M LAN port (LAN1)
Terminal
Block
1 x 8-bit digital I/O by Pin header or connector
（GPIO/GPIO1）
4-bit digital Input
4-bit digital Output
1x VCC
1x GND
Power
Button
1x Power on/off switch (SW1)
1x Green Power LED
Serial 2 x RS232 header for internal (COM2,COM4)
Audio Support Line-in, Line-out, MIC by 2x6 pin header
（F_AUDIO）
KB/MS 1 x PS/2 keyboard pin heade （PS2）
1 x PS/2 Mouse pin header
(2) Location:
