BCI Mini-3GHD User’s Manual
Miniature Fiber Optic 3Gb/s HD-SDI Digital Video Transport System
Broadata Technical Support, (800) 214-0222 10
If you have any problems or concerns, regarding the installation, make
sure that you have taken the proper steps to ensure a proper power
connection. Otherwise, feel free to contact us for any questions you
may have.
3.0 OPERATION
After the installation procedure is completed, the units are ready for
operation. To operate the BCI Mini-3GHD units, simply apply power as
indicated in the previous step. Note that the following front panel link
status indicator, shown in Table 2 will be activated.
4.0 MAINTENANCE AND TROUBLESHOOTING
4.1 Maintenance
There is no operator maintenance other then keeping the units
clean. However, observe the following light indicators to make
sure that the unit is working properly:
Table 2
Status Indicators
OPT (TX)
This BLUE LED is on when the Mini-3GHD-T unit has been
powered properly.
This WHITE LED is on when laser output is activated. This
also indicates HD-SDI video signal is presented.
PWR (TX)
PWR (RX) This BLUE LED is on when the Mini-3GHD-R has been
powered properly.
This WHITE LED indicates the received optical power
level.
OPT-LEVEL
