Conversion to LPG
Conversion procedure
Injectors replacement
Select the injectors to be replaced
according to the “Table for the choice of
the injectors” (page 14).
To replace the injectors proceed as fol-
lows:
- Remove pan supports and burners
from the cooktop.
- Using a wrench, substitute the nozzle
injectors “J” (fig. 3.3, 3.4) with those
most suitable for the kind of gas for
which it is to be used.
The burners are conceived in such
a way so as not to require the regu-
lation of the primary air.
Minimum burner setting
adjustment
In the minimum position the flame must
have a length of about 4 mm and must
remain lit even when turned quickly
from the maximum position to minimum.
The flame adjustment is done in the fol-
lowing way:
- Turn on the burner
- Turn the tap to the MINIMUM position
- Take off the knob
- With a small flat screwdriver turn the
screw inside the tap rod to the cor-
rect regulation (fig. 3.5).
Normally for G30/G31, the regulation
screw is tightened up.
