13 CR-iMAX901HD Multiple Signals Scaler User Manual
Impedance 100 Ω
Input EDID Use the system default EDID,( Supports EDID mapped to the input terminal)
The maximum DC
bias error
15mV
Recommended
maximum
input
distance
The input distance is less than 25 meters;output less than 10 meters,in
1920x1080p@60(you’re recommended to use the certified HDMI dedicated
wire, such as the Molex TM wire.)
Supported resolution
640x480@60Hz;800x600@60Hz;1024x768@60Hz;1280x720@60Hz;1280x
800@60Hz;1280x960@60Hz;1280x1024@60Hz;1360x768@60Hz;1366x76
8@60Hz;1400x1050@60Hz;1440x900@60Hz;1600x1200@60Hz;1680x105
0@60Hz;1920x1080@50Hz;1920x1080@60Hz;1920x1200@60Hz
DisplayPort video
Interface
20-pin DP interface, standard,1 DisplayPort input
Supported protocols DisplayPort 1.1
Maximum
transmission delay
500us
Transmission
bandwidth
The maximum of transmission bandwidth is 10.8Gb/S
Supported resolution
640x480@60Hz;800x600@60Hz;1024x768@60Hz;1280x720@60Hz;1280x
800@60Hz;1280x960@60Hz;1280x1024@60Hz;1360x768@60Hz;1366x76
8@60Hz;1400x1050@60Hz;1440x900@60Hz;1600x1200@60Hz;1680x105
0@60Hz;1920x1080@50Hz;1920x1080@60Hz;1920x1200@60Hz
HDBaseT video
Interface
RJ-45 female interface;1 HDBaseT input,1 HDBaseT output
Supported protocols Conform to HDCP standard
Maximum pixel clock 225MHz
Impedance 100Ω
Recommended
maximum
input
distance
The maximum transmission distance is ≤100m(use standard Cat5 enhanced
or Cat6 cable)
Supported resolution
640x480@60Hz;800x600@60Hz;1024x768@60Hz;1280x720@60Hz;1280x
800@60Hz;1280x960@60Hz;1280x1024@60Hz;1360x768@60Hz;1366x76
8@60Hz;1400x1050@60Hz;1440x900@60Hz;1600x1200@60Hz;1680x105
0@60Hz;1920x1080@50Hz;1920x1080@60Hz;1920x1200@60Hz
Audio signal
Input/output interface
9 3-pin phoenix joint/each has unbalanced audio input,Balanced audio
amplifier output of 1 4-pin phoenix joint
Gain 0 dB
Frequency response 20 Hz~20 kHz,
THD + Noise 0.05%@1 kHz (with rated voltage)
Signal-to-Noise(S/N ) >80dB
Stereo separation >80dB@1 kHz
