Ports and Connectors
Digital Input/Output
The Digital I/O connector provides powering-on function to an external device
that is connected to this connector.
Pin
Digital Output/ Input
Pin Assignment
1 DIO1
2 DIO2
3 DIO3
4 DIO4
5 DIO5
6 DIO6
7 DIO7
8 DIO8
9 GND
