Hardware Installation
COM1/COM2 RS232/Power Select
JP1
JP3
2 4 6
1 3 5
2 4 6
1 3 5
1-3, 2-4 On: RS232
(default)
3-5 (+5V), 4-6 (+12V)
On: RS232 with power
1-3, 2-4 On: RS232
(default)
3-5 (+5V), 4-6 (+12V)
On: RS232 with power
2
1 3 5
4 6
1 3 5
2 4 6
