DFI SR100-L20C User Manual
Page 21
Advertising
2
21
Hardware Installation
LAN
USB 0
USB 1
1
r
Important:
When you install the CPU fan and heat sink assembly, make
sure the assembly is positioned in such a way that the direc-
tion of the airflow blows towards the Northbridge. This is to
ensure optimum thermal condition and system performance.
