18
7 0 0 S E R I E S O W N E R’ S M A N U A L
Electrical Construction:
Power: External power; 110VAC/220VAC wall mounted
adapter
Wiring: 22 AWG Copper, PVC jacketed
Console: High Impact ABS plastic, Circuit Board: FR4 Fiber-
glass, LED 3-Color Dot matrix Display, One
Numeric Window, 14 LED Indicators, Built-in
Reading Rack
Console
Feedback:
Time, RPM/SPM, Calories, Pulse, Distance, Level
Programming
Options
• Manual Mode with Quick Start Option
• 4 Pre-Programmed Hill Profiles with 16 intensity levels
• Heart Rate Control Program
Heart Rate: • Built-in Polar compatible heart rate receiver
• Contact heart rate standard
• Polar compatible chest strap included
Mechanical Construction:
Brake System: Electronically Controlled Magnetic Brake (ECB)
Flywheel: 24lbs. Balanced.
Drivetrain: Fiber reinforced Wingprene Poly-V Belt, 6 groove.
Bearing: High quality bearings in Bottom Bracket &
Sealed ball bearings in brake
Frame: Welded Fourteen (14) Gauge Steel Tubing.
Paint: Polyester epoxy powder coating. Wrinkle fin-
ish, electrostatically applied.
Side Cases: High Impact, ABS Plastic
Hardware: SAE 1020 with BED Finish
Upholstery: Polyurethane Emerald Surface Foam
Foam Grip: PVC Nitrile Rubber
Operating
Specifications:
Resistance range 25 to 750 watts.
User Weight
Capacity:
U, R: 250 lbs./113 kgs; EL: 300lbs./136kgs
Maintenance
C A U T I O N - FOR SAFE OPERATION
Always inspect hardware prior to any exercise session. Look for loose hardware, loose pedals, loose cranks, and frayed wires. Repair or
replace any damaged or worn parts, tighten all loose hardware.
As part of Diamondback’s normal installation and set-up process, all pedals/cranks must be tightened after 8 to 10 hours of initial riding
to ensure parts are properly seated. This is standard initial “break in” service which must be performed after the first 8 to 10 hours of use.
Untightened pedals/cranks may become loose, causing damage which may void warranty.
After training, always wipe down your 700 series unit. Perspiration that continuously settles on frame, pads or casing may eventually
cause rust or damage to the unit. Damage resulting from lack of proper maintenance will not be covered under warranty. To clean pads,
use a mild soap and warm water. Dry with clean towel.
If noises develop or malfunctions occur, contact your authorized Diamondback fitness dealer.
Specifications
Space & Weight Requirements
Shipping Specifications Assembled Specifications
700U Upright 85 lbs. / 38”Lx16”Wx29”H 71 lbs. / 35”Lx22”Wx55”H
(38.5 kgs. / 952mmLx401mmWx726mmH) (32 kgs. / 889mmL x 560mmW x 1397mmH)
700U Recumbent
104 lbs. / 45”Lx17.5”Wx29”H 95 lbs. / 57”Lx27”Wx47”H
(47 kgs. / 1127mmLx438mmWx726mmH) (43 kgs. / 1450mmL x 700mmW x 1194mmH)
700EL Elliptical
168 lbs. / 63”Lx27”Wx31”H 152 lbs. / 59”Lx26”Wx58”H
(76.3 kgs./1600mmLx690mmWx780mmH) (69 kgs. / 1500mmL x 650mmW x 1480mmH)
