DNF Controls SW32PS_Port_Switcher - Manual (Page 2)

Page 1 of 24 SW32PS RS422 Port Switcher
TABLE OF CONTENTS
1. REVISION HISTORY 3
GETTING STARTED . . . 4
2. DESCRIPTION 4
3. INSTALLATION 4
4. OPERATION 6
a. MAKE A ROUTE 6
b. VIEW THE ROUTES 6
c. SETUP GANG 6
d. SAVE PRESET 7
e. RESTORE PRESET 7
f. DISCONNECT ROUTE 7
g. DISCONNECT GANG 7
ADVANCED FEATURES . . . 8
5. SOFTWARE OPTIONS 8
a. GRASS VALLEY 7000 INTERFACE OPTION 8
b. PESA INTERFACE OPTION 10
c. SIGMA INTERFACE OPTION 11
6. COMPUTER INTERFACE PROTOCOL 12
COMMANDS 12
7. SELF-TEST PROCEDURE 15
a. KEYBOARD TEST 15
b. SYSTEM PORT TEST 15
c. FACTORY TEST ROUTES 16
d. TEST IN/OUT PORTS 16
e. TEST RS232 INTERFACE 17
f. TEST RS422 INTERFACE 17
