SFP Video Network Settings Mac Address, IP address, Subnet Mask, Default Gateway, and HTTP Server Enable
SFP Port HTTP Server Enable, “ Enabled”: This will allow management capability on the same SFP port (SFP
port IP Address) as the streaming video.
SFP Control-Only VLAN Settings: Enable, Tag, IP address, Subnet Mask, and Default Gateway
VLAN Enable, “Enable”: This will allow management capability on the same SFP port using VLAN IP address.
Control Port Ethernet Settings: Mac Address, IP address, Subnet Mask, and Default Gateway
Unit Description: Unit Name and User Location – User logged values
SNMP Settings: Trap IP address, Trap Target Port, System Contact
Web Settings: User Timeout- 5 minutes to 30 minutes
System Configuration Tab
The system configuration tab allows the user to set Ethernet and SNMP settings
1
2
3
4
5
6
2a
1a
