Note: Grill must be connected to 120VAC power for electronic lighting.
1. Open lid(s) or remove cover(s) from burner(s) to be lit.
2. Turn all gas control knob(s) to their OFF position(s).
3. Turn on the gas at its source.
Note: DO NOT turn on more than one valve at a time for either electronic or manual lighting.
4. Depress the desired control knob for 5 seconds, then, while pressing turn it counterclockwise
to the HI LIGHT position. Once the burner lights, release the knob.
CAUTION: If a burner does not light within fi ve (5) seconds of turning on the control knob, depress the
knob and turn it to the OFF position. WAIT FIVE (5) MINUTES before repeating step 4. If
the burners still do not light after several attempts, refer to the LIGHTING INSTRUCTIONS
in your grill owner's manual.
5. Repeat step 4 for each additional burner to be lit.
4-Grill Setup
Parts Placement Checklist
Place the following items according to their position and orientation in
Fig. 4-1:
Flavor grids, cooking grids, backburner cover, warming rack, meat
probe.
Leave pre-installed E-burners in place to maintain proper alignment.
Backburner Cover (if equipped)
Hook the backburner cover over the top of the backburner to protect
the backburner from grease, dust and dirt when it is not in use.
Remove cover before use.
Warming Rack
The warming rack comes pre-installed. Remove zip ties before use.
Consult the owner’s manual to remove or replace.
Fig. 4-1
Cooking Grid
Flavor Grid
(not with IR)
Backburner
cover
Warming
rack
Rotisserie
rod storage
bracket
Front support
adjustment
screws (2)
Center main burner control knob
(only on A540i and larger units) Fig. 5-2
Left
main burner
control knob
Right main burner
control knob
Backburner
control knob
(if equipped)
Digital
thermometer
Meat probe Pull-out
drip tray
Note: For infrared burner equipped grills,
see detailed instructions included
in your owners manual.
Meat
probe
Drip tray
liners
Drip tray
(with lighting instructions)
5-Test
Fig. 5-1 - Burner valve control knob
OFF
HI
LIGHT
LOW
T
O
TURN OFF
T
O
TURN
ON
Read setting
here
HIGH to
LIGHT
To
Turn
OFF
To
T
urn
ON
High to
light
Read setting here
6-Propane Safety
FOR PROPANE CONFIGURATIONS; READ ALL SAFETY INSTRUCTIONS AND WARNINGS REGARDING THE USE OF PROPANE
GAS FOUND IN YOUR OWNERS MANUAL.
WHEN OPERATING THIS
APPLIANCE WITH PROPANE,
ALL INSTRUCTIONS AND
WARNINGS MUST BE
OBSERVED. FAILURE TO DO
SO MAY RESULT IN A FIRE
OR EXPLOSION CAUSING
SERIOUS INJURY OR DEATH.
E-burner *
(pre-installed)
* The burner ports
and carry-over slots
must be kept clean to
ensure proper ignition
and operation.
Light
switch
Light
switch
Grill lights
(not shown)
