Status displays
G&D Dynamic-UserCenter 32 · 15
How to enable the interface status of Dynamic Ports:
1. In the tree view, click UserCenter .
2. Right-click the device, and select Dynamic Port LEDs > Show status from the menu.
3. Choose System to show the port modes of all ports, or choose the port group to
which you want to limit the highlighting LEDs to.
The LEDs of the Dynamic Ports now highlight the current status of the single ports
(see table above).
