29

67

29

23

1

61

13

FRAME ASSEMBLY

NOTE:
- WRENCH TIGHTEN HARDWARE.
- INSTALL CABLE AND PULLEYS AT THE
SAME TIME.
- SOME PARTS MAY HAVE BEEN
REMOVED FOR CLARITY.

HD-3200 ASSEMBLY

OWNER'S MANUAL

PAGE 16
