Hoist Fitness RPL-5403-B - Manual (Page 32)

ITEM NO. PART NUMBER DESCRIPTION QTY.
1 026-01X3629 BASE FRAME ASSEMBLY 1
2 026-01X3789 BASE FRAME SUPPORT ASSEMBLY 1
3 026-01X3634 SEAT FRAME ASSEMBLY 1
4 026-01X3630 PRESS ARM FRAME ASSEMBLY 1
5 026-01X3631 BELL-CRANK ASSEMBLY 1
6 026-01X3633 PUSH LINK ASSEMBLY 1
7 026-01X3635 PULL LINK ASSEMBLY 1
8 026-01X3100 LOCKOUT HANDLE ASSEMBLY 1
9 026-01X3108 BACK PAD ADJUSTER ASSEMBLY-A 1
10 026-01X3107 BACK PAD ADJUSTER-B 1
11 026-01X3109 SHOULDER PAD FRAME ASSEMBLY 1
12 026-01X3114 BACK PAD ADJUSTING HANDLE ASSEMBLY 1
13 026-01X3118 WEIGHT PEG 3
14 026-01X3121 FOOTPLATE MOUNT 1
15 022-01PD2205-A HEAD PAD ASSEMBLY 1
16 022-01PD2086-A BACK PAD ASSEMBLY 1
17 022-01PD0082-A SHOULDER PAD ASSEMBLY 2
18 026-01X5630 CHAIN LINK REPLACEMENT 1
19 026-01PL2264 RUBBER FOOTPLATE COVER 1
20 026-01M1142 COUNTER WEIGHT 2
21 026-01M0936 ALUMINIUM RING: 1.00" I.D. 3
22 026-01M0935 ALUMINIUM RING: Ø1.50" I.D. 1
23 026-01M1151 SHAFT: 1.00 X 5.47 LG. 1
24 026-01M2905 SHAFT - 1.181 X 4.7100 LG. 2
25 026-01X3636 SHAFT PULL LINKS UPPER RPL-5403 1
26 026-01M1139 SPACER: 1.75 X 2.78 LG. 2
27 026-01M2904 SHAFT - .984 X 1.7610 LG. 2
28 026-01M2652 SPACER 2
29 026-01M1176 HANDLE END CAPS 1
30 026-01M0937 END CAP: ALUMINUM 1.0" I.D. 2
31 026-01M0932 ALUMINIUM CAP: Ø1.25" ID 1
32 026-01M0128-1 PULL PIN CAP 1
33 026-01M0128-3 PULL-PIN PLUNGER 1
34 026-01M0209 PULL-PIN TO CHAIN LINK 1
35 026-01P3284 PLATE: 5.00" X 9.2500 2
36 026-01P3938 FOOT PLATE 1
37 026-01P3917 LOWER FOOTPLATE 1
38 026-01PL2246 DUAL HOLE BUMPER 2.05" THICK 2
39 026-01PL2005 PLUG BUMPER (2 STEM) 3
40 026-01PL2158 PLASTIC KNOB: Ø1.50" - BASE 1
PART LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
OWNER'S MANUAL
PAGE 31 RPL-5403-B ASSEMBLY
