1
117
64
64
105
49
32
FRAME ASSEMBLY
NOTE:
- INSTALL CABLE AND PULLEYS AT
THE SAME TIME.
- WRENCH TIGHTEN HARDWARE.
- SOME PARTS MAY HAVE BEEN
REMOVED FOR CLARITY.
OWNER'S MANUAL
V-EXPRESS ASSEMBLY
PAGE 34
49
105
1
GUARD BOLT
105
1
49
BE SURE TO POSITION CABLE (1)
BETWEEN PULLEY (49) AND PREVIOUSLY
INSTALLED GUARD BOLT (105), AS SHOWN.
PROPERLY INSTALLED VIEW
