Parts List
63
Part #
Qty
Name
3117
2
6 Spoke Wheel Shiny Chrome (83x56mm)
4464
2
Gt Tires S Compound (160x86mm)
6122
10
Body Pin (Medium)
6123
20
Body Pin (Large/8mm)
6154
10
Nylon Strap (3.5x150mm/black)
6163
5
Servo Tape 20x100mm
6749
4
Shock Spring 14.4x117x1.4mm 26 Coils (Black)
6811
8
O-ring 6x9.5x2mm (Black)
6816
6
Silicone O-ring S10
6819
5
Silicone O-ring P-3 (Red)
6898
4
Silicone O-ring P31
6899
6
O-ring 5x8x1.5mm
72130
1
Stainless Steel Slipper Plate
72131
2
Slipper Clutch Pad
73915
1
Main Chassis 2.5mm (Blue)
76914
1
Transmission Gear 44 Tooth (1m/2 Speed)
76924
1
Transmission Gear 39 Tooth (Savage Hd 2 Speed)
76942
1
Spur Gear 52 Tooth (1m)
85044
1
Diff Case Set
85045
1
Gear Box/bulkhead Set
85046
1
Center Gear Box
85047
1 Pair
Suspension Arm Set
85048
1 Axle
Upright Set
85049
2 Shocks Shock Body Set
85050
2 Shocks Shock Parts/rod End Set
85058
1
Steering Crank/servo Saver Set
85059
1
Bumper Set/long Body Mount Set
85060
1
Skid Plate/body Mount/shock Tower Set
85061
1
Radio Box Set
86030
1
Bevel Gear 43 Tooth (1m)
86031
1
Bevel Gear 13 Tooth (1m)
86032
1
Bevel Gear Set (Gear Diff)
86055
2
Shock Shaft 3x86mm (Silver)
86056
1
Dogbone 8x84mm (Black)
86057
1
Dogbone 8x78mm (Black)
86058
2
Dogbone 9x123mm (Black)
86059
4
Ball 6.8x7.3x3mm (Black)
86060
1
Engine Mount
86061
1
Exhaust Header (Rear Exhaust)
86062
2
Joint Post 4x7x74mm
86063
2
Engine Mount Brace 7x7x74mm
86064
2
Diff Shaft 14x34mm (Black)
86065
2
Axle 8x9x44mm (Black)
86066
4
Hex Wheel Hub 14mm (Silver)
86067
1
Bulkhead Lower Plate 2.5mm (Purple)
86068
2
Upper Arm Brace 4x54x3mm (Purple)
86069
1
Engine Plate 2mm (Purple)
86070
2
Lower Arm Brace 4x54x3mm (Purple)
86071
2
Flange Shaft 4x62mm (Black)
86072
2
Threaded Shaft M4x70mm (Black)
86073
2
Shaft 4x78mm (Silver)
86074
2
Shaft 4x46mm (Silver)
86076
1
Pilot Nut 1/4-28x8.5mm (Black)
86077
1
Collet 7x6.5mm (Brass/21 Size)
86081
1
Gear Shaft 6x12x78mm (Black)
86082
2
Cup Joint 6x13x20mm (Black)
86083
2
Cup Joint 8x19mm (Black)
86084
1
Drive Gear 32 Tooth (1m)
86087
1
Clutch Gear Holder With One-way (Silver)
86088
1
Idler Shaft 6x8x45mm (Black)
86089
1
Drive Shaft 6x71mm (Black)
86090
2
Steering Crank Post 6x49mm (Black)
86092
1
Brake Cam/piston Set
86094
6
Screw Shaft M4x2x12mm (Black)
86095
6
Screw Shaft M5x3x18mm (Black)
86097
1
Drive Gear 18-23 Tooth (1m)
86098
1
Idler Gear 29 Tooth (1m)
86110
1
Tuned Pipe (Composite Nylon/savage)
86121
4
Washer 5x10x3mm (Brass)
86130
1
Slipper Clutch Hub
Part #
Qty
Name
86132
1
Axle 8x9x44mm (Counterclockwise Threaded/silver)
86153
1
Roll Bar (Blue)
86271
1
Flywheel 34mm (3pin)
86318
1
Brake Hub (Alloy Cast/silver)
86319
1
Steering Post 12x47mm (Purple)
86356
1
Brake Linkage Set
86368
1
Clutch Holder (Savage Hd 2 Speed/assembled)
86369
1
Clutch Hub (Savage Heavy Duty 2 Speed)
87031
1
Fuel Tank (160cc)
87040
1
Silicone Exhaust Coupling 12x18x30mm (Purple)
87041
2
Rubber Cap For Gear Box
87042
1
Spring 4.9x8x7mm/washer 4.3x10x1.0mm(Hex Hole) Set
87049
2
Shaped Exhaust Gasket (21 Size)
87053
1
Brake Disk/plate Set
87054
1
Exhaust Manifold Spring 3.2x75x0.7mm X56
87058
8
Rubber Tube 3x8x10mm (Shaped/black)
87151
3
Teflon Clutch Shoe/spring Set
87193
1
4 Bevel Gear Differential Conversion Set (1set)
87194
4
Shaft For 4 Bevel Gear Diff 4x27mm
87199
1
Air Cleaner Sleeve Set (For #87198)
87204
1
Air Cleaner Foam Element Set (For #87198)
94036
10
Button Head Screw M2x5mm
A989
1
Heavy-duty Clutch Bell 14 Tooth (1m)
B021
2
Ball Bearing 5x10x4mm
B023
2
Ball Bearing 6x13x5mm
B032
2
Ball Bearing 10x16x5mm
B072
6
Metal Bushing 5x11x4mm
B085
2
Ball Bearing 8x16x5mm
Z150
1
Antenna Pipe Set
Z224
10
Washer M3x8mm
Z235
4
C Clip 20mm
Z240
4
C-clip 8mm
Z243
10
E Clip E3mm
Z245
10
E Clip E5mm
Z260
12
Pin 2.5x12mm
Z282
4
Step Screw M3x14mm
Z286
6
Step Screw 3x20mm
Z288
4
Step Screw 4x20mm
Z303
6
Cap Head Screw M3x42mm
Z481
12
Tp. Binder Head Screw M2.6x8mm
Z488
6
Tp. Flanged Screw M2.6x12mm
Z517
10
Binder Head Screw M3x8mm
Z520
6
Binder Head Screw M3x18mm
Z526
6
Flat Head Screw M3x8mm
Z530
6
Flat Head Screw M3x18mm
Z543
6
Cap Head Screw M3x10mm
Z544
6
Cap Head Screw M3x12mm
Z547
6
Cap Head Screw M3x20mm
Z561
6
Tp. Flanged Screw M3x10mm
Z567
10
Tp. Binder Head Screw M3x10mm
Z569
10
Tp. Binder Head Screw M3x15mm
Z578
10
Tp. Flat Head Screw M3x12mm
Z581
10
Tp. Flat Head Screw M3x18mm
Z613
6
Binder Head Screw M4x10mm
Z632
6
Tp. Binder Head Screw M4x10mm
Z634
10
Tp. Binder Head Screw M4x15mm
Z644
10
Tp. Flat Head Screw M4x15mm
Z661
4
Lock Nut M2.6
Z663
6
Lock Nut M3
Z682
4
Flanged Lock Nut M5 (Clockwise/black)
Z683
4
Flanged Lock Nut M5 (Counterclockwise/silver)
Z684
4
Flanged Lock Nut M4
Z685
10
Washer 2.7x6.7x0.5mm
Z694
10
Washer M5x10x0.5mm Silver
Z700
6
Set Screw M3x3mm
Z721
4
Set Screw M4x4mm
Z792
6
Cap Head Screw M4x8mm
Z897
6
Washer 12x18x0.2mm
