HPI Racing Pro 4 Hara Edition - Manual (Page 34)

34
Parts List
Part # Qty Discription Part # Qty Discription
Part # Qty Discription
30004
50432
6151
6163
6273
6274
6542
6543
6544
6545
6546
6547
6548
6820
6871
72013
72015
72044
72063
72105
72111
72302
72446
73079
73080
73081
73109
73501
73506
73507
73508
73510
73511
73512
73513
73514
73516
73517
73518
73519
73522
73523
73524
73825
75100
75105
75106
75108
75109
75111
75112
75115
75116
75119
75120
75121
75122
75125
75126
75127
75135
75140
75143
75144
75151
75156
75158
75159
75160
75161
75162
75167
75168
75169
75179
75190
75192
75194
75196
75197
75198
75199
SHOCK SPRING ADJUST NUT (PURPLE)
O-RING S-12 (BLACK)
SILICONE SHOCK OIL #500
SERVO TAPE 20x100mm
FOAM SPACER FOR FOAM BUMPER
PRECUT FOAM BUMPER GRAY
RACING SHOCK SPRING 14x25x1.4mm 6 COILS (BLUE)
RACING SHOCK SPRING 14x25x1.5mm 6.5COILS(SILER)
RACING SHOCK SPRING 14x25x1.5mm 6 COILS(GOLD)
RACING SHOCK SPRING 14x25x1.5mm 5.75 COILS (WHITE)
RACING SHOCK SPRING 14x25x1.5mm 5.5 COILS (YELLOW)
RACING SHOCK SPRING 14x25x1.5mmx5.25 (RED)
RACING SHOCK SPRING 14x25x1.5mmx6.25 (PINK)
SILICONE O-RING P-3 (CLEAR)
SHOCK SHAFT 3x28mm
MIP CVD REBUILD KIT
THREAD LOCK (MIP)
THIN ALUMINUM HEX HUB (PURPLE)
CONE WASHER 3.0mm/4-40 FLATHEAD (PURPLE)
DIFF RING D CUT TYPE
SHIM SET 3x5mm (M3x5x0.1-0.2-0.3mm)
BALL SET FOR SWAY BAR
BALL 3x4.7x6mm
FRONT SHOCK TOWER
REAR SHOCK TOWER
STEERING PLATE
UPPER DECK 2.25mm
BEVEL GEAR SET (39T/16T/SPACER)
CARBON GRAPHITE SUSPENSION ARM SET
CARBON GRAPHITE BLOCK AND HUB SET
STEERING PARTS SET
SHOCK PARTS/BALL END SET
CARBON GRAPHITE GEARBOX SET
BRACE/BATTERY MOUNT/GAUGE SET
BUMPER/BODY POST SET
CARBON GRAPHITE OUTDRIVE/DRIVE CUP SET
CARBON GRAPHITE C HUB SET (0 DEGREES)
CARBON GRAPHITE C HUB SET (2 DEGREES)
CARBON GRAPHITE C HUB SET (4 DEGREES)
CARBON GRAPHITE C HUB SET (6 DEGREES)
DIFFERENTIAL SCREW AND HEAVY-DUTY NUT SET
BLADDER 12x3.5mm (FLAT TYPE)
MACHINED SHOCK PISTON (1.1mm 3 HOLES)
MAIN CHASSIS 2.5mm
FOAM RING 1.5x9x3mm
ALUMINUM MAIN DRIVE SHAFT 6.3x163mm (PURPLE)
BODY CLIP (6mm/BLACK)
INPUT SHAFT RETAINER (PURPLE)
INPUT SHAFT SPACER (PURPLE)
CUP JOINT 6mm
STEERING POST 4x33.5mm
BALL STUD 4.3x10.3mm (2mm SOCKET)
BALL STUD 4.3x13mm (2mm SOCKET)
SUSPENSION SHAFT 2.5x24.5mm
SUSPENSION SHAFT 3x41mm
PIVOT BALL 3x5mm
STEERING BLOCK BUSHING
SWAY BAR 1.2mm (COPPER)
SWAY BAR 1.4mm (SILVER)
SWAY BAR 1.6mm (BLACK)
DIFF OUTDRIVE RING
FRONT ONE-WAY DIFFERENTIAL 39TOOTH
SERVO SAVER SET
PIVOT BLOCK SPACER SET
PIVOT BLOCK F/R (PURPLE)
PIVOT BLOCK 0 DEGREES (PURPLE)
PIVOT BLOCK 1 DEGREES (PURPLE)
PIVOT BLOCK 1.5 DEGREES (PURPLE)
PIVOT BLOCK 2 DEGREES (PURPLE)
PIVOT BLOCK 2.5 DEGREES (PURPLE)
PIVOT BLOCK 3 DEGREES (PURPLE)
ALUMINUM SERVO MOUNT 10mm (PURPLE)
FRONT SOLID AXLE SET (SPOOL)
DELRIN OUTDRIVE SET
ALUMINUM INPUT SHAFT SET (FRONT AND REAR/PURPLE)
ONE-WAY GEAR BRACE (PURPLE)
ALUMINUM MOTOR MOUNT (PURPLE)
COMPETITION ALUMINUM THREADED SHOCK SET (46-56)
ALUMINUM THREADED SHOCK BODY (46-56mm)
SHOCK CAP 15x5.5mm (PURPLE)
SHOCK CAP BOTTOM 11x5mm (PURPLE)
SHOCK RETAINER SET
4
5
1
5
8
1
2
2
2
2
2
2
2
8
2
1
1
1
6
1
10
1
4
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
4
1
1
1
20
1
2
2
2
4
4
2
2
4
4
2
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
Optional Parts
76598
80824
80827
80828
93462
93464
94036
A046
A150
A157
A162
A165
A166
A301
A302
B012
B015
B020
B021
B030
Z082
Z083
Z087
Z150
Z155
Z156
Z159
Z164
Z203
Z216
Z234
Z242
Z264
Z273
Z305
Z350
Z352
Z353
Z354
Z356
Z438
Z541
Z653
Z675
Z679
Z700
Z705
Z724
Z775
Z814
Z817
Z819
Z852
Z891
Z892
Z901
Z903
Z904
Z950
Z960
SPUR GEAR 98 TOOTH (DELRIN/64PITCH)
MIP CVD AXLE
MIP CVDS (PURPLE)
MIP CVD BONE 6x46mm (PURPLE)
TITANIUM TURNBUCKLE M3x24mm (PURPLE)
TITANIUM TURNBUCKLE M3x29mm (PURPLE)
BUTTON HEAD SCREW M2x5mm
O-RING P3 BLACK
BALL 2mm
CARBIDE DIFFERENTIAL BALLS (3/32 in./2.4mm)
DIFFERENTIAL SCREW M2x25mm
SPRING 6x7x1.5mm BLACK
DIFF THRUST WASHER 2.2x6mm
HEAVY-DUTY BALL CUP 4.3x13mm
HEAVY-DUTY BALL CUP 4.3x18mm
BALL BEARING 3x6x2.5mm (FLANGED)
BALL BEARING 4x7x2.5mm
BALL BEARING 5x8x2.5mm
BALL BEARING 5x10x4mm
BALL BEARING 10x15x4mm
FLAT HEAD SCREW M3x8mm (HEX SOCKET)
FLAT HEAD SCREW M3x10mm (HEX SOCKET)
FLAT HEAD SCREW M3x20mm (HEX SOCKET)
ANTENNA PIPE SET
DIFFERENTIAL LUBE
GRAY DIFFERENTIAL LUBE
THREAD LOCK
HEAVY WEIGHT GREASE
WASHER M3x6mm
BUTTON HEAD HEX SOCKET SCREW M3x15mm
CAP HEAD SCREW M2x5mm
E CLIP E2mm
PIN 2x10mm SILVER
PIN 1.6x8mm
SCREW POST M3x15mm
BUTTON HEAD SCREW M3x5mm (HEX SOCKET)
BUTTON HEAD SCREW M3x8mm (HEX SOCKET)
BUTTON HEAD SCREW M3x10mm (HEX SOCKET)
BUTTON HEAD SCREW M3x12mm (HEX SOCKET)
BUTTON HEAD SCREW M3x18mm (HEX SOCKET)
BINDER HEAD SCREW M2x4mm
CAP HEAD SCREW M3x6mm
NUT M3
ALUMINUM THIN LOCK NUT M3 (PURPLE)
WHEEL NUT M4 (PURPLE)
SET SCREW M3x3mm
SET SCREW M3x10mm
SET SCREW M4x8mm (ROUND POINT)
SET SCREW TP3.2x5mm
ALUMINUM WASHER 3x6x0.75mm (PURPLE)
ALUMINUM WASHER 3x6x2.0mm (PURPLE)
ALUMINUM WASHER 3x6x3.0mm (PURPLE)
WASHER 5x7x0.2mm
WASHER 10x12x0.1mm (COPPER)
WASHER 10x12x0.2mm
ALLEN WRENCH 1.5mm
ALLEN WRENCH 2.5mm
ALLEN WRENCH 2.0mm
CROSS WRENCH
TURNBUCKLE WRENCH
1
2
2
1
2
2
10
4
12
12
2
2
2
8
8
2
2
2
2
2
10
10
10
1
1
1
1
1
10
4
10
20
10
12
4
10
10
10
10
10
10
6
6
5
5
6
6
6
6
10
10
10
10
10
10
1
1
1
1
1
73085
73825
73826
75053
75165
75170
75172
75174
75175
Z046
73086
GRAPHITE CAMBER PLATE
MAIN CHASSIS 2.5mm
MAIN CHASSIS 3.0mm
CERAMIC NITRIDE DIFFERENTIAL BALL (2.4mm)
CHASSIS WEIGHT SET
HEATSINK MOTOR PLATE (PURPLE)
DELRIN PIVOT BALL 3x5mm
DELRIN BEARING ADAPTER (from 5x10x4 to 5x8x2.5)
PRO 4 SPRING SET (ID14mmxL25mm)
TITANIUM MOTOR SCREW M3x6mm (PURPLE)
GRAPHITE BUMPER BRACE
1
1
1
12
1
1
8
8
1
2
1
En
Refer to page 38 39 for parts contents.
