Easy pan, tilt & zoom controls for any RS-232 VISCA protocol camera!
Controls pan & tilt with variable speeds of slow / medium / fast.
Use 2 & 3 dimensional joystick with “twist” control of focus and zoom.
Key Product Features .
 Metal housing.
 VISCA, PELCO-D and PELCO-P protocol support.
 English / Chinese LCD display.
 Key-press “BEEP” confirmation.
 Variable speed control of pan, tilt & zoom.
 Speed step control adjustments.
 Pan, tilt, rotation, zoom, iris, focus and camera settings.
 Preset tour, pattern, absolute position, zoom operation, AUX operation.
 Real time display of the current status.
 Short circuit & overcurrent protection.
 Automatic recovery program for the communication port(s).
Key Technical Specifications .
 RS-485 semi duplex, RS-422 full-duplex, RS232 full-duplex.
 Baud Rate 1200/2400/4800/9600bps.
 Interfaces
 RJ45: RS485,
 Screw Terminal: RS485/RS422, RS232, DB9.
 Maximum communication distance:
3,937ft (1200m) using 24 gauge twisted pair cabling.
 Can control a maximum 256 cameras.
 Voltage: 12VDC.
 Power: 5W.
 Display: LCD.
 Working Temperature: 14°F ~ 122°F (-10° ~ +50° C).
 Working Humidity: 10 ~ 90% (non-condensation).
 Weight 2.32 lbs.
 Dimensions:
10.69”(L)X 7.5”(W)X 4.06(H) [271mm(L)X 191mm(W)X 103.2mm(H)].
