6
DO-IT-YOURSELF MAINTENANCE
40
PROTECTED COMPONENTS
FUSE RATING
FUSE
P/AMP
20A
Audio amp
DR LOCK
20A
Door lock/unlock relay
HAZARD
10A
Hazard relay
P/SEAT RH
30A
Power seat manual switch(RHD)
A/BAG IND
10A
Instrument cluster
T/SIG
10A
Turn signal light
CLUSTER
10A
BCM(Body Control Module), Instrument cluster, Yaw rate sensor, ESP switch, Seat warmer
AGCS
10A
(Spare)
START
10A
Start relay
PEDAL ADJ
15A
(Spare)
ECS/RR FOG
15A
Rear fog light relay
T/LID OPEN
15A
Trunk lid relay, Fuel filler door and trunk lid switch
S/HTR
15A
Seat warmer switch
P/SEAT LH
30A
Power seat manual switch
SPORT MODE
10A
Sport mode switch, Key solenoid
MIRR HTD
10A
A/C control module, Outside mirror and mirror folding motor
POWER CONNECTOR. 1
15A
Audio
POWER CONNECTOR. 2
15A
BCM(Body Control Module), Digital clock, Instrument cluster, A/C control module, Courtesy lights,
Interior light
