INSTALLATION AND CONNECTION
The VaporGuard™ system is a factory installed
option and is shipped attached to the warewasher.
Refer to Warewasher installation instructions.
Check Electrical Connections
Warewasher to VaporGuard™ Inlet damper solenoid
Warewasher to VaporGuard™ Bypass damper
solenoid
Warewasher to VaporGuard™ Blower motor
Note these connections are 208/240VAC.
Setting Up and Alignment:
The machine must be completely level when
installed.
Adjust the machine’s feet to compensate for any
unevenness of the floor.
Check and retighten connections of exhaust hose/
duct to bypass damper and to VaporGuard™
Check exhaust hose/duct to ensure that it does not
extend below the VaporGuard™ box inlet at any point
along its path. Adjust as required.
Connection to the Drain:
The unit is equipped with a 1/2” PVC drain
connection and is normally connected to the same
drain that the warewasher is connected to. The drain
must be connected to a drain capable of handling
an additional 1.0 gal/min flow. A proper air gap must
be supplied between the unit and the building drain
connections. Failure to provide air gap will result in
improper or inconsistent draining of unit and potential
overflow condition.
