(4) JP8 (6-pin): COM3 Header Pin9 Function Select
3-4 closed : +12V;
JP8
1-2 closed: RS232;
1
5-6 closed : +5V
1
1
(5) JP9 (3-pin): : Mini PCI-E Power VCC3.3V/ 3.3VSB Function Select
2-3 closed: MINI PCI-E VCC=3.3VSB
JP9
1-2 closed: MINI PCI-E VCC= VCC3.3V;
JP9
