3-7-3 Onboard Super IO Function
Phoenix – AwardBIOS CMOS Setup Utility
Onboard Super IO Function
Item Help
Onboard FDD Controller Enabled
Onbo ard Serial Port1 3F8/IRQ4
Onboard Serial Port2 2F8/IRQ3
UART2 Mode Select Normal
* IR Duplex Mode Half
Onboard Parallel Port 378/IRQ7
Parallel Port Mode SPP
*ECP Mold Use DMA 3
Menu Level >>
↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Optimized Defaults F7:Standard Defaults
Onboard FDD Controller
Select Enabled if your system has a floppy disk controller (FDD) installed on the system board
and you wish to use it. If you install add-on FDC or the system has no floppy drive, select
Disabled in this field. The settings are: Enabled and Disabled.
Onboard Serial Port 1
The optional settings are：Disabled, 3F8/IRQ4，2F8/IRQ3, 3E8/IRQ4，2E8/IRQ3, 4E0/IRQ4,
4E8/IRQ3 and Auto.
Onboard Serial Port 2
The optional settings are：Disabled, 3F8/IRQ4，2F8/IRQ3, 3E8/IRQ4，2E8/IRQ3, 4E0/IRQ4,
4E8/IRQ3 and Auto.
UART2 Mode Select
This item allows you to determine which InfraRed(IR) function of the onboard I/O chip. The
optional settings are Normal and IrDA.
IrDA Duplex Mode
This field is available when UART Mode is set to either ASKIR or IrDA. This item enables you
to determine the infrared function of the onboard infrared chip. The options are Full and Half
