20
3.1.3. ESATA/USB 2.0 Port
The function of this connector depends on different device connected to this connector through
different cable.
It could function as:
„ E-SATA connector when a compatible ESATA hard disk is connected to it through SATA cable.
„ USB 2.0 connector when a compatible USB device is connected to it through USB cable (for
device connection please refer to 3.1.1 ).
ESATA/USB 2.0port
ESATA Cable
ESATA Hard Disk
