Kemppi 5001 Master User Manual
Page 5
Advertising
MASTER 5001/0541 – 5
©
KEMPPI
OY
H12
H11
S11
X11
X13
X14
01
F11
F11 Fuse for remote control connection 1,0 A delayed
H11 Signal lamp I/O
H12 Warning lamp for thermal shield
S11 Main switch I/O
X11 Welding and earth connection
X 13 Welding and earth connection
X14 Remote control connection
01 Inlet of mains cable
