P A R T S L I S T 24 24
Ref Description Part # Qty Ref Description Part # Qty
1 Hood assembly P0014708MA 1
2 Hood handle P00205087B 1
2a Hood handle bracket – left P00301016E 1
2b Hood handle bracket – right P00302016E 1
3 Temperature gauge P00601011B 1
4 Protective pad P05518002I 2
5 Cooking rack / secondary P01516003A 1
6 Grill plate P01615028E 5
7 Bowl panel – rear P06906025C 1
8 Bowl wind shield P06906026C 1
9 Grease tray heat shield – upper P06901014A 1
9a Grease tray heat shield – lower P06901015A 1
10 Infrared burner assembly P02005009A 4
11 Bowl panel – front / rear P0075401JA 2
12 Bowl panel – front upper P0075501JA 1
13 Bowl panel – rear upper P0075601JA 1
14 Bowl grease shield – lower front P06902015C 1
14a Bowl grease shield – lower rear P06902016C 1
15 Bowl grease shield – upper P06902014C 2
16 Bowl panel – left P0072076EC 1
17 Bowl panel – right P0072176EC 1
18 Bowl grease shield – upper, left / right P06901003A 2
19 Bowl grease shield – lower, left / right P06902017C 2
20 Manifold assembly – propane Y0060418 1set
20 Manifold assembly – NG Y0060419 1set
20a Manifold – for valves P05005222F 1
20b Gas Valve heat shield P03009161B 1
20c Gas valve – left (without jet), propane P03243001A 2
Gas valve – left (without jet), NG P03243002A 2
20d Gas valve – right (without jet), propane P03243003A 2
Gas valve – right (without jet), NG P03243004A 2
21 Control panel – upper P02909351S 1
22 Control panel – lower, with screen print P02909796A 1
23 Control knob seat P03413011J 4
24 Knob P03419473L 4
25 Electric igniter – 4 port P02502184C 1
25a Electric wire set – 4 contact P02615099A 1
26 Electric wire with electrode – left front P02618003C 1
26a Electric wire with electrode – left rear P02618004C 1
27 Electric wire with electrode – right front P02618005C 1
27a Electric wire with electrode – right rear P02618006C 1
28 Connector with infrared orifice – propane P06536003A 4
Connector with infrared orifice – NG P06536004A 4
29 Gas connector – rear P03701013A 2
29a Gas connector – front P03701014A 2
30 Thermocouple protector P03343003A 4
31 Electrode bracket – LF / RR P03343001A 2
32 Electrode bracket – RF / LR P03343002A 2
33 Thermocouple – LF / RF P05305014A 1
34 Thermocouple – LR / RR P05305015A 2
39 Manifold connector P03715005A 1
40 Gas manifold – rear, propane P05005222A
Gas manifold – rear, NG P05005232A 1
40a Brass fitting with test point P03906009A 1
41 Grease / water tray P02717184A 1
41a Grease tray handle P02720023C 1
41b Wheel for grease tray P05354002A 4
42 Trolley partition panel P01003050D 1
42a Trolley panel cap P05535003P 1
43 Bowl support bracket – left P01301004B 1
44 Bowl support bracket – right P01302004B 1
45 Door top support P03306030C 1
46 Trolley left panel P07614011A 1
47 Trolley right panel P07615011A 1
48 Trolley rear side panel P07701069A 1
49 Door support bracket – upper left P03302033A 1
50 Door support bracket – upper right P03302034A 1
51 Castor seat – LF P05327021T 1
52 Castor seat – RF P05327023T 1
53 Door panel – left P04302044A 1
54 Door panel – right P04303045A 1
55 Door handle P00214004A 2
56 Spice rack P05204011B 1
57 Name plate P00410040G 1
58 Cylinder pull-out tray assembly Y03400048 1set
59 Trolley bottom shelf P01009043C 1
60 Castor seat – RR P05327024T 1
61 Castor seat – LR P05327022T 1
62 Castor P05110006D 4
63 Door guide plate P05510024A 1
64 Door magnet P05523001K 4
65 Towel rack P05212003B 1
66 Wing bolt S233G05591 1
67 Regulator P03603004A 1
Hardware pack P06003083A 1
