FUSE
BATTERY FAULT
TIMEOUT
BULK CHARGE
FINISH CHARGE
BATTERY CHARGED
BAT
+ #2 #1
TEMP. SENSE OUTPUT
L N
INPUT
CHARGING WIRE SIZE
VOLTS AWG
12
24
32
36
48
72
96
120
10
12
12
14
16
16
16
16
+
-
THERMISTOR (OPTIONAL)
BATTERY
BLACK
GREEN
WHITE A.C. INPUT
POWER
Figure 2
INSTALLATION WIRING
