Indicator installation hole template – Kussmaul Electronics 091-53-12-REMOTE User Manual

Page 6

Advertising
background image

#8-32 HEX NUT

TRUCK WALL

GASKET

INDICATOR

LOCK & FLAT WASHER

8-32 SCREW

INDICATOR INSTALLATION

HOLE TEMPLATE

File: Ind.cdr rev C: 3-31-10 do not shrink this art work

Hole Template may not be to Scale, please check dimensions before using.
