Table 2 – Stainless Steel Band Selector Chart
NOTE: Intermediate and larger size bands are available on special order.
4.0 - OPERATION
4.1
Manual Band Crawler
Manual operation of the Band Crawler is controlled by rotating the Crank Handle of the 9’ / 2.7m or 14’/ 4.3m
Flexible Drive Cable Assembly. It can be turned in either direction, for either clockwise or counterclockwise
rotation of Band Crawler around the Stainless Steel Band that is mounted to the pipe.
4.2
Motorized Band Crawler
The CE Motorized Band Crawler is available in a 230 vac model. Motorized operation is controlled with the
European version of the Mathey Dearman Motor Control Box. Forward / Stop / Reverse Switch on Motor Control
Box determines clockwise and counterclockwise rotation of Band Crawler around the pipe. The Speed Control
Knob controls speed of rotation around the pipe. The Motor Control Box is equipped with Emergency Stop
Pipe Size
Latch Type Standard
Weight (approx.)
Inches
mm
lbs.
kg.
6
152
05-0104-006
5
2
8
203
05-0104-008
6
3
10
254
05-0104-010
7
3
12
304
05-0104-012
7
3
14
356
05-0104-014
11
5
16
406
05-0104-016
12
5
18
457
05-0104-018
13
6
20
508
05-0104-020
14
6
22
559
05-0104-022
15
7
24
610
05-0104-024
24
11
26
660
05-0104-026
25
11
28
711
05-0104-028
25
11
30
762
05-0104-030
25
11
32
813
05-0104-032
26
12
34
864
05-0104-034
27
12
36
914
05-0104-036
29
13
38
965
05-0104-038
31
14
40
1016
05-0104-040
33
15
42
1067
05-0104-042
36
16
44
1118
05-0104-044
39
18
46
1168
05-0104-046
43
20
48
1219
05-0104-048
90
41
50
1270
05-0104-050
92
42
52
1321
05-0104-052
96
44
54
1372
05-0104-054
100
45
56
1422
05-0104-056
106
48
58
1473
05-0101-058
110
50
60
1524
05-0104-060
115
52
